Main Chipset

MT7603

Host interface

USB 2.0 Type A

LED

Link/ Activity

Antennas

One PCB antenna, one rotatable antenna.

Operation Frequency

ISM band , 2412~2483.5MHz (Depends on country regions).

Typical Transmit Power

802.11b (CCK) 11Mbps: 18+/-1dBm

802.11g (OFDM) 54Mbps: 15+/-1dBm

802.11n (HT20@MCS7), 14+/-1dBm，(HT40@MCS15),14+/-1dBm

Receive Sensitivity

802.11b: -88+/-1dBm； 802.11g: -73+/-1dBm

802.11n (HT20), -71+/-1dBm；802.11n (HT40), -68+/-1dBm

Operation System

Windows XP/Vista/7; Linux 2.6.X; Mac OS X

Security

WEP 64/128, WPS;WPA/WPA2 (TKIP,AES); WAPI

Voltage Range/Current

DC 5.0V ± 5% / <300mA @802.11g

Physical Specification

Dimensions

63*21*11mm（without external antenna）

Weight

18g
